D-Link DAP-2695 WLAN access point - Networking device

D-Link DAP-2695 WLAN access point - Networking device

(0 Reviews)
Category: Wireless Access Points
Availability: Out of Stock
Part Number: DAP-2695
Manufacturer: D-Link
Payment Methods: Visa American Express Discover Mastercard PayPal
Inc. VAT
MSRP:
Ex. VAT
MSRP:

-You Save:



REQUEST A QUOTE

Request a quote below or call 02079938331 for further assistance with this part number

Get exclusive discounts on bulk orders

Super-fast Wireless AC PerformanceThe DAP-2695 delivers reliable, high-speed wireless performance using the latest 802.11ac standards with maximum wireless signal rates of up to 450 Mbps over the 2.4 GHz band, and 1300 Mbps over the 5 GHz band. This, coupled with support for the Wi-Fi Multimedia (WMM) Quality of Service (QoS) feature, makes it an ideal access point for audio, video, and voice applications. When enabled, QoS allows the DAP-2695 to automatically prioritize network traffic according to the level of interactive streaming, such as HD movies or VoIP. The QoS feature can be adjusted through the DAP-2695’s web GUI using a drop-down menu option to select customized priority rules. Additionally, the DAP-2695 supports load balancing to ensure maximum performance by limiting the maximum number of users per access point.Versatile Access Point FunctionalityThe DAP-2695 allows network administrators to deploy a highly manageable and extremely robust simultaneous dual-band wireless network. All six antennas on the DAP-2695 are detachable and can provide optimal wireless coverage over either the 2.4 GHz (802.11b, 802.11g, and 802.11n) or the 5 GHz (802.11a, 802.11n, and 802.11ac) band. Enclosed in a plenum-rated metal chassis, the DAP-2695 adheres to strict fire codes for placement in air passageways. For advanced installations, the DAP-2695 has integrated 802.3at Power over Ethernet (PoE) support, allowing this device to be installed in areas where power outlets are n

Data transmission
Ethernet LAN data rates10,100,1000 Mbit/s
Data transfer rate (max)1750 Mbit/s
Performance
2.4 GHzYes
5 GHzYes
Frequency band2.4, 5
Quality of Service (QoS) supportYes
Networking standardsIEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u
ModulationDSSS,OFDM
Management platformHTTP/Telnet//SNMP, MIB
Ethernet LAN data rates10,100,1000 Mbit/s
CertificationFCC, IC, CE, UL, Wi-Fi
Data transfer rate (max)1750 Mbit/s
Wireless LAN features
Frequency band2.4, 5
ModulationDSSS,OFDM
Networking
InternalNo
Networking standardsIEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u
Ports & interfaces
WAN connectionEthernet (RJ-45)
Ethernet LAN (RJ-45) ports2
DC-in jackYes
Security
Security algorithms128-bit WEP,64-bit WEP,802.1x RADIUS,HTTPS,SSH,WPA,WPA2
Security featuresNAP
MAC address filteringYes
Authentication methodRADIUS
Management features
Quality of Service (QoS) supportYes
Management platformHTTP/Telnet//SNMP, MIB
Antenna
Antenna typeExternal
Antennas quantity6
Antenna gain level (max)6 dBi
Certificates
CertificationFCC, IC, CE, UL, Wi-Fi
Power
Power over Ethernet (PoE)Yes
Input voltage48
Design
InternalNo
LED indicatorsYes
Indication
LED indicatorsYes
Operational conditions
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 65 °C
Storage relative humidity (H-H)5 - 95%
Weight & dimensions
Width190 mm
Depth198.8 mm
Weight1.14 kg
Height36.5 mm
